Mini Duplex Light Bar

Giá: Liên hệ


Technical Specifications

4-Cluster Type
Dimensions: L605 x W284 x H119 mm
Solar Panel: 20W
Storage Battery: DC 12V 12Ah
LED: 18 x 8 = 144 ea

2-Cluster Type
Dimensions: L336 x W284 x H119 mm
Solar Panel: 10W
Storage Battery: DC 12V 12Ah
LED: 18 x 4 = 72 ea

Features:

Automatically detects external light and adjusts brightness across 4 levels depending on the surrounding environment.
Smart digital brightness control. Dims at night and brightens during the day, enhancing battery efficiency and improving daytime visibility.
Battery life is maximized by using intelligent charging circuits.
Power efficiency is optimized by applying an LED switching control network.
Uses super-bright LEDs to emit brighter light.
The sturdy metal frame provides strong protection against external impacts.

Installation Locations:

Installed at intersections or areas requiring traffic warnings or specific guidance.

Origin: South Korea

Technical Drawing

4-Cluster Type

2-Cluster Type

Document
